To significantly calm and darken your room, up to 100% of UV light.
Utilizing unique construction and advanced materials Portrait™ is made to insulate better. Experience fabric technologies that will make you feel more comfortable and save on energy
Glacier White C4001
Steel Gray C4101
Terra C4102
Mineral C4103
Slate C4104
Dusk C4105
Infinity C4108
Champagne C4111
Black Ink C4201
Mocha C4402
Flax C4410
Espresso C4411
Ecru C4412
Desert C4504
Primrose C4506
Tamarind C4507
Sand C4508
Pebble C4509
Brie C4510
Eggnog C4514
Fog Green C4601
Indigo C4704
Topaz C4705
Larkspur C4802
Lift System/Product | Width | Length | Max Area (sqft) | ||
---|---|---|---|---|---|
Min | Max | Min | Max | ||
Cord Loop & SmartRelease™ | 15" | 120" | 10" | 144" | 80 |
Cord Loop TD | 24" 1 | 120" | 10" | 144" 1 | 80 |
Corded | 8 1/2" | 96" | 25 1/2" | 144" | 60 |
Corded TDBU | 8 1/2" | 96" | 25 1/2" | 144" | 60 |
Product | Mounting | Shade Width(X) | Shade Height(Y) | PVC light guard length | ||||
---|---|---|---|---|---|---|---|---|
Order Width | Measurement | Tolerance | Order Height | Measurement | Tolerance | |||
Cord Loop | OB | X=Order Width | Measure shade from left to right | ±1/8" | Y=Order Height | Measure from the top of the headrail to the bottom of bottom rail (when the shade is at full extension) | +3/8" ~ +1 1/4" | N/A |
SmartRelease™ | ||||||||
Cord Loop TD | IB | X=Order Width-3/8" | ±1/8" | Y=Order Height | Order Height - 1/8" | |||
Corded | OB | X=Order Width | ±1/8" | Y=Order Height | +1/4" ~ +3/4" | N/A | ||
Corded TDBU |
Lift Systems | 3/8" Single | 9/16" Single | 1/2" Double | 3/4" Single | 3/4" Double | 1 1/4" Single | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
Inside Mount | Semi-IM | Inside Mount | Semi-IM | Inside Mount | Semi-IM | Inside Mount | Semi-IM | Inside Mount | Semi-IM | Inside Mount | Semi-IM | |
SmartRelease™ | 2 1/4" | 1 5/16" | 2 1/4" | 1 5/16" | 2 1/4" | 1 5/16" | 2 1/4" | 1 5/16" | 2 11/16" | 1 7/16" | 2 11/16" | 1 7/16" |
Cord Loop | 2 1/4" | 1 5/16" | 2 1/4" | 1 5/16" | 2 1/4" | 1 5/16" | 2 1/4" | 1 5/16" | 2 11/16" | 1 7/16" | 2 11/16" | 1 7/16" |
Cord Loop TD | 2 1/4" | 1 5/16" | 2 1/4" | 1 5/16" | 2 1/4" | 1 5/16" | 2 1/4" | 1 5/16" | 2 11/16" | 1 7/16" | 2 11/16" | 1 7/16" |
Corded | 1 1/16" | 1 1/16" | 1 3/4" | 1 5/16" | 2" | 1 5/16" | 2" | 1 5/16" | 2 11/16" | 1 1/2" | 2 11/16" | 1 1/2" |
Corded TDBU | 1 1/16" | 1 1/16" | 1 3/4" | 1 5/16" | 2" | 1 5/16" | 2" | 1 5/16" | 2 11/16" | 1 1/2" | 2 11/16" | 1 1/2" |
For more detailed information about the product, its specifications, options and technical manuals.
Portrait™ Honeycomb Shades - Program Reference Guide
Continuous Cord Loop - Installation Instructions
