Roller Shades Group 3

Factory Specifications

Minimums and Maximums

	Cordless Roller	Clutch Roller
Minimum Width:	18"	6"
Maximum Width:	73"	108"
Minimum Height:	12"	12"
Maximum Height:	96"	96"

Depth Requirements

Roller Shade depth requirements are affected by several variables, such as: the size of the roller tube (depends on the shade width), the thickness of the fabric, and the overall shade height. Please review the chart below to determine if you have enough window depth for inside mount.

Additional Information

• Roller shade sizes are based on tip-to-tip measurements.
• Roller shade fabric is 1” less than the tip-to-tip measurement on shades produced on 1 1/4” and 1 1/2” tubes.
• Roller shade fabric is 1 1/8” to 1 1/4” less than tip-to-tip measurement on shades produced on 2” and 3” roller. (except Motorized - 1 7/8” difference)
• When ordering an outside mount shade, determine the width you desire the fabric to be and add 1” for the tip-to-tip measurement.
• Additional fabric is added to ordered height to allow for roller coverage and spring tension.
• Sizes exceeding fabric width are made from railroaded cloth (using width for height) therefore any pattern will run sideways. Railroading fabric will accommodate a wider width shade but will in turn limit the height of the shade to the fabric width minus 12” unless the fabric is seamed.
• Not all fabrics are available with a horizontal seam to accommodate larger size shades.

Features and Benefits

• Cordless operation. - Child safe. Eliminates dangling cords and chains.
• Minimal mounting space required. - Many choices can be mounted behind other treatments to add privacy, then simply rolls out of the way when not needed.
• Flame-retardant fabric choices. - Appropriate for commercial applications.

Standard Items

• Standard hem - aluminum (or wooden) hem slat heat sealed into hem pocket.
• Standard roll - shade material comes off the back of the roller. Recommended for most applications.

• Decorative scallop and trim options
• Aluminum or wrapped hem bar.
• Reverse roll - shade material comes off the front of the roller. Leaves noticeable light gap. Best suited for duplex fabrics.
• Shade pulls available for cordless/spring roller.
• Ez Lift clutch system easily lifts large shades while the continuous chain loop stays the same length. Allows precise positioning of shade.
